Hydraulic Road Blockers

- High emergency impacts
- Short operating times
- Long-term anti-orrosion protection

anti-ram vehicle road blockers are being operated world-wide for perimeter securing of entrances to highly sensitive areas.

Complex Access Control:

road blockers offer maximum security for vitally sensitive areas against unauthorized entry of vehicles of all sizes and weights. Road Blockers can be installed as single units or in combination with another product (hydraulical barrier, security gate) in order to achieve a access control check-point. In operation, the heavy blocking segment raises (via controller or from quard checkpoint) within few seconds and blocks the access with a blocking height of 650 mm or higher (950mm , 110mm in special versions). Warning colours and the up to 4 warning lights makes it easy to see the blocking segment, so approaching vehicles can stop in time. The visual impact is minimum, but efficient to keep an unwanted person away from the entrance.

High Crash Impacts

produces high security anti-ram vehicle barriers which are effective way to stop even very large unauthorized vehicles from entering the possession. Our barriers can stop a large lorry, driving 80 km/h, without any damage for the barrier itself. It is installed in army and navy building, embassies, government buildings, airports and some other important public service places and car parking and as an anti-terrorist measure. We are proud to have installed some of our barrier for NATO building. The size can be adjusted to the special need of the customer.

Technical Description

- powerful electro-hydraulic drive unit
- all structural components made of highest grade steel with high impact strength
- wall thickness of structural components 10 - 15 mm
- impact loads up to 2 x 2.500 kN
- blocking height 650 mm (or up to 110mm in special versions)
- blocking width up to 6 m
- electro-hydraulic drive unit in separate protective housing up to 15/20 meter from installation depending on the model
- fast operating periods: approx 5/6 seconds as stanadard (approx. 2 seconds in special version)
- high wheel load (100 kN) according to european standards
- blocking segment with hydraulic locking
- impact element with warning signs and from 2 up to 4 large warning lights
- hand pump for emergency operation in case of power failure
- Control equipment possibilities: push button, magnetic/digital card reader, remote radio control, emergency STOP, key switch OPEN/STOP/CLOSE,
- Acessoires: semaphore ligthning RED/GREEN on separate post, photocells, emergency power supply from UPS, induction loops depending othe requirements, cooler, counter, water pump

Applications of road blockers

- embassies
- seats of government
- warehouses
- research and computer establishments
- courts
- banks
- places of detention
- power stations
- supply depots
- industrial plants
- military areas
- airports
- high security areas

Photo Gallery
